Programmable Room Thermostat

programmable room thermostat

PM51 series thermostat, designed to be used in underfloor heating system, is to control the temperature of indoor room according to the preset temperature values. Simple and elegant design make it perfect for any style of decor. There are four models for option, meeting the requirements of different floor heating systems, electric floor heating or hydronic floor heating system. The product is able to set four time periods in a day: period of waking up, leaving home, back home and sleeping. This helps to tailor a comfort home according to your need and achieve energy saving.

The operation is simple. Many setting interfaces can be entered by pressing one or two designated buttons for 5 seconds.

PM51 WiFi models enable you to control the room temperature anytime and anywhere, and to upgrade the software online.

Features of the programmable room thermostat

• A large, clear 3.5-inch display screen
• Customize your own schedule with a weekly programmable feature
• Energy-saving window-open detection
• Preheat function lets you reach your desired temperature before the next scheduled period
• Child lock feature to avoid accidental adjustments
• Easy to operate
• Wi-Fi control lets you adjust room temperature anytime and anywhere

Technical data

Voltage: AC220V/AC230V 50Hz

Rated power:＜1.5W

Terminal blocks: one terminal can be connected to

2*1.5mm² or 1*2.5mm² wire at most.

Signal terminal: 0.75mm²wire

Temperature range: 5~90℃

Measuring range: -9.5~99.5℃

Protection class: IP20

Ambient temperature: -10~55℃

Selection table
