Both electronic type and electromagnetic type relay available upon request;
Min tripping power:100uVA;
Magnetizing power:≥5000uVA;
Resetting force: 1.2N-1.6N;
Impedance when tripping power adjusted into 100uVA: 160 turns: 2.8-4.4Ω; 500 turns: 35-45Ω;
Plunger path distance:1.8mm;
Characteristics of path force:
Min tripping power:100uVA;
Magnetizing power:≥5000uVA;
Resetting force: 1.2N-1.6N;
Impedance when tripping power adjusted into 100uVA: 160 turns: 2.8-4.4Ω; 500 turns: 35-45Ω;
Plunger path distance:1.8mm;
Characteristics of path force:
path distance:0.5mm: F≥0.8N; path distance:1.0mm: F≥0.5N; path distance:1.5mm: F≥0.25N;
Tripping time:25ms when incentive value bigger than 20% of adjusted tripping power;
Life:5000 times;
Weight:8g.
Tripping time:25ms when incentive value bigger than 20% of adjusted tripping power;
Life:5000 times;
Weight:8g.
Customized relays available upon request.
Therefore Application of CONTACTOR RELAY
The electromagnetic solid-state residual current circuit breaker (RCCB) with relay function serves as a crucial safety device. It detects and protects against leakage currents in an electrical circuit. This solid-state device, equipped with relay capabilities, swiftly interrupts the circuit upon sensing any abnormal leakage. It effectively prevents electrical shock accidents caused by leakage and ensures personal safety. The advanced solid-state technology employed in this contactor relay guarantees reliable performance. For distribution and supply, it is made available through trusted relay distributors.
